Standard ABS shell with metal frame featuring customer-supplied TV provision, security sliding door, and ergonomic non-slip ladder. Perfect for hotels, airports, and commercial applications.

Model short description

GALAXY — Horizontal Single is the single horizontal model in the GALAXY Series series. It is made for pod hotels, hostels, hospitals, airports and railway rest spaces with linear layouts, using Taiwan Chi-Mei V0 fire-retardant ABS + high-quality metal with practical features like Intelligent LED multifunction control panel with back-lit number plate, Internal security lock with stainless-steel handle, Reading light, mirror light & ceiling light. This model is suitable when buyers want a ready commercial sleeping-pod option with clear sizing, service support, GST billing and India delivery planning.

Model type

single horizontal

Series

GALAXY Series

Best for

Commercial rest spaces

What you get with each pod

Intelligent LED multifunction control panel with back-lit number plate

Internal security lock with stainless-steel handle

Reading light, mirror light & ceiling light

Adjustable ventilation (two inlets/outlets, ~30 m³/h)

Ergonomic non-slip ladder with security sliding door

Fire-retardant ABS shell (Taiwan Chi-Mei)

110-240 V universal lighting power, ~60 W typical consumption

Available in 8 colours including Green

ABS sliding door with anti-pinch edge

Smoke alarm system inside each capsule

Backrest of explosion-proof tempered glass

Antiskid ladder with safety handrail

LED multifunctional entry guard + number plate

Capsule external body including ladder

Capsule internal safety anti-theft lock

Safety stainless-steel handle

Intelligent LED multifunction capsule space number plate

Manual integrated intelligent central control panel

Simple-style ceiling

Circular luxury mirror

Adjustable changing-wind air-condition circulatory system

Space aluminum clothes hook

Advanced bedplate: fire-retardant, anti-bug, anti-mildew and anti-deformation

Reading light

Colorful mirror light

Capsule space number plate backlight

Leather-surface colour options: white, pink, blue, black, yellow and silver

Air-condition circulatory system with two air inlets/outlets and control-panel air-speed adjustment

Fresh air ventilation: 30 m³/h

110V–240V international power support

Low-voltage 12V lighting power supply

Power consumption per capsule bed: approx. 60 W idle, approx. 110 W with a customer-supplied display

Pricing basis: EXW (Ex-Works) per piece — one set = upper + lower = 2 pcs; add-ons billed separately

3D model — drag to rotate

Interactive 3D view of the horizontal flagship pod. Click and drag to spin, scroll to zoom. On mobile: pinch to zoom, two fingers to rotate.

Length

2050 mm

Width

1150 mm

Height (2-pod stacked)

4800 mm

Size & details

SKU / Item code: BP-1002
HSN code: 94037000
Material: Taiwan Chi-Mei V0 fire-retardant ABS + high-quality metal
Single pod size: External 2050 × 1150 × 2400 mm | Internal 2000 × 950 × 1050 mm | Ladder 300 mm
Stacked set size: 2050 × 1150 × 4800 mm (L × W × H — full set of 2 pods stacked, per manufacturer spec)
Bed Size: single
Orientation: horizontal
Origin: Imported
Category: capsule-bed
Factory Model Codes: TWS-801, TWS-802, TWS-803
Colours: White, Pink, Yellow, Black, Blue, Green, Orange, Grey
